Sunlight Readable
EVERVISION provides sunlight readable display for customers. Our Sunlight Readable TFT Series is featured with brightness up from 800 nits to 1800 and is suitable for outdoor applications.
Control board, Touch panel, Interface (MCU, TTL RGB, eDP, LVDS, and MIPI) can be optionally available depend on customer's requirement.
-
.jpg "VGG322425-A(SR)")
3.5" Sunlight Readable TFT
Model No. VGG322425-A(SR)
- Size (inch):3.5
- Resolution (dots):320*240
- Outline Dimensions (mm):76.9*63.9*3.3
- I/F Mode:TTL RGB
- Brightness (TYP.):800 / 30khrs typ.
- LED Driver:NO
- Touch Panel:(Option)
-
3.5" Sunlight Readable TFT LCD
Model No. VGG322425-B(SR)
- Size (inch):3.5
- Resolution (dots):320*240
- Outline Dimensions (mm):76.9*63.9*3.3
- I/F Mode:TTL RGB
- Brightness (TYP.):800 / 30khrs typ.
- LED Driver:NO
- Touch Panel:(Option)
-
3.5" Sunlight Readable TFT LCD LCM
Model No. VGG322425-D(SR)
- Size (inch):3.5
- Resolution (dots):320*240
- Outline Dimensions (mm):76.9*63.9*3.3
- I/F Mode:TTL RGB
- Brightness (TYP.):800 / 30khrs typ.
- LED Driver:NO
- Touch Panel:(Option)
-
3.5" Sunlight Readable TFT LCD Module
Model No. VGG322425-F(SR)
- Size (inch):3.5
- Resolution (dots):320*240
- Outline Dimensions (mm):76.9*63.9*3.3
- I/F Mode:TTL RGB
- Brightness (TYP.):900 / 30khrs typ.
- LED Driver:NO
- Touch Panel:(Option)
-
3.5" Sunlight Readable TFT Panel
Model No. VGG322425-H(SR)
- Size (inch):3.5
- Resolution (dots):320*240
- Outline Dimensions (mm):76.9*63.9*3.3
- I/F Mode:TTL RGB
- Brightness (TYP.):900 / 30khrs typ.
- LED Driver:NO
- Touch Panel:(Option)
